WarDragon Running KrakenSDR to TAK Python and Federate TAK Server

Over on YouTube Aaron, creator of DragonOS and the WarDragon portable SDR kit has posted a video showing how he was able to set up an run the KrakenSDR to TAK python software, as well as a Federate TAK server on WarDragon. Aaron writes:

In this video, we delve into the integration between the KrakenSDR and TAK (Tactical Assault Kit) server, orchestrated by SignalMedic. SignalMedic introduces his Python-based update to his previous NodeRed-dependent system, designed to extract data from the KrakenSDR and relay it to a TAK server.

Witness the capabilities of SignalMedic's creation as we showcase its functionalities with two KrakenSDR endpoints, transmitting lines of bearing and other information to our TAK server setup. We explore setting up and running SignalMedic's project on a WarDragon, a custom kit powered by DragonOS that I've enhanced with a KrakenSDR specifically for this demonstration.

Join us as we demonstrate the integration between the KrakenSDR and the TAK server, showcasing the ease of setup and operation, thanks to previous tutorials on setting up a TAK server and configuring inputs for KrakenSDR data streams. We address challenges encountered during communication between TAK servers and discuss the manual certificate import process from SignalMedic's server to ensure smooth operation.

Additionally, we touch upon federating two TAK servers to enable seamless information sharing between environments, enhancing situational awareness and operational efficiency.

I also mention the perviously explored the Goatak project, an ATAK client for Linux written in GO, which promises to expand the capabilities and accessibility of TAK operations on Linux platforms.

In the past we posted about SignalMedic's KrakenSDR to TAK converter, but it was recently updated to be written in full Python, so it no longer requires the NodeRED dependency.

If you weren't already aware, KrakenSDR is our 5-channel coherent radio based on RTL-SDRs, and it can be used for applications like radio direction finding. It can be purchased on Crowd Supply.

TAK (Tactical Assault Kit) is software used by the military and other organizations for visualizing geospatial information such as enemy and friendly positions. Civilian versions of TAK also exist, such as ATAK for Android. Previously we posted about how ATAK has the ability to plot aircraft positions via an RTL-SDR receiving ADS-B.

WarDragon KrakenSDR to TAK Python + Federate TAK Server w/ K2T Developer (KrakenSDR)

A KrakenSDR to TAK Interface Converter

Thank you to RTL-SDR.COM reader Aaron, who recently found a Kraken-to-TAK converter made by "SignalMedic" and "dngrssgnls" which converts the KrakenSDR bearing output data to "Cursor on Target" (COT) or XML format, allowing common TAK interfaces to read and display the data. Currently the converter allows a line of bearing to be displayed in a TAK app, with arbitrary length. The converter consists of a single json file for Node Red. The GitHub readme reads:

Convert data from a Kraken SDR to TAK endpoints

The software will parse information collected by Kraken, convert to COT and XML and send to common TAK interfaces. The length of the line is arbitrary. The line is 6km long, but has no correlation besides bearing to the transmitter. Intersecting bearing lines are necessary for determining the geolocation of a transmitter.

Planned improvements include:

  • Button for persisting the current line and generating a new UID
  • Work on filtering out by DOA Angle node
  • Dashboard for easier updating of Kraken and TAK endpoints
  • Simplified deployment

We note that most TAK apps may be a little limited for direction finding purposes as they cannot calculate bearing intersections over time, or calculate a bearing grid like the KrakenSDR Android app, and KrakenSDR online web mapper does. However, often a single line of bearing is enough information, especially if there are multiple distributed units contributing bearing data.

If you weren't already aware, KrakenSDR is our 5-channel coherent radio based on RTL-SDRs, and it can be used for applications like radio direction finding. It can be purchased on Crowd Supply.

TAK (Tactical Assault Kit) is software used by the military and other organizations for visualizing geospatial information such as enemy and friendly positions. Civilian versions of TAK also exist, such as ATAK for Android. Previously we posted about how ATAK has the ability to plot aircraft positions via an RTL-SDR receiving ADS-B.

KrakenSDR bearing data displayed on a TAK app.
